Denotes that the product is Kitemarked
| SL NO. | DRAWING NO. | CLEAR OPENING AXB (in mm) | OVERBASE CXD (in mm) | GRADE | HEIGHT H (in mm) | GRP PROVISION | KITEMARKED |
|---|---|---|---|---|---|---|---|
| 1 | AIPPL-001 | 600×600 | 745×745 | D-400 | 100 | Yes | – |
| 2 | AIPPL-101 | 600X600 | 680X680 | D-400 | 75 | Yes | – |
| 3 | AIPPL-101A | 600×600 | 680X680 | D-400 | 75 | Yes | – |
| 4 | AIPPL-101B | 600×600 | 680X680 | B-125 | 75 | Yes | – |
| 5 | AIPPL-076 | 600×600 | 715X760 | D-400 | 100 | Yes | |
| 6 | AIPPL-080 | 600×750 | 870×720 | D-400 | 100 | Yes | – |
| 7 | AIPPL-143 | 750×750 | 875X875 | D-400 | 100 | Yes | – |
| 8 | AIPPL-152 | 800×800 | 909X909 | D-400 | 100 | Yes | – |
| 9 | AIPPL-127 | 900×900 | 1070X1070 | D-400 | 100 | No | – |
| 10 | AIPPL-085 | 900×750 | 1020×870 | D-400 | 100 | Yes | – |
| 11 | AIPPL-128 | 1200×1200 | 1500X1500 | D-400 | 100 | Yes | – |
| 12 | AIPPL-079 | 600×900 | 1020X720 | D-400 | 100 | Yes | |
| 13 | AIPPL-126 | 1200×900 | 1350X1050 | D-400 | 100 | Yes | – |
